KCHR-8I/BP Side Wind All In One Heat Pump Water Heater 3.88 COP
NegotiableDomestic Air Source Heat Pump All In One Heat Cooling And Hot Water9DHW) With Enamel Water Tank
KCHR-8I/BP Side Wind All In One Heat Pump Water Heater 3.88 COP
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CB, CE, EMC, RoHS
Model Number: KCHR-8I/BP Side wind
High Light:

IPX4 All In One Heat Pump


33A All In One Heat Pump


3.88 COP All In One Heat Pump

Payment & Shipping Terms
Packaging Details: export package Woonden case or plastic film
Delivery Time: 1-30 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50,000pcs/year
Install: Flexible, Separate Or Install Together Are Both Ok
Working Ambient Temperature: -30-50℃
After Sale Service: Free Spares Supply 24 Months Warranty
Power Ranges: 10-200KW
Low Noise & Vibration: ≤60db(A), Depends On Machine
Type: Air To Water Air Source Heat Pumps
Product Description

Product Introduction of High Efficiency Air Source Heat Pump Water Heater
A heating device that absorbs the heat energy of the air in the environment to heat water, because the power consumption is only 1/4 to 1/3 of the direct electric heating method, and it is less affected by the regional environment, and it can operate stably throughout the year Therefore, the air-energy hot water machine has become a new energy-saving hot water heating device. According to whether the compressor is equipped with a jet enthalpy increase device, the air-energy cold and hot water machines are divided into two categories: conventional type and ultra-low temperature type. Among them, the conventional air-energy hot water machine can operate stably for a long time in the environment of -7℃~43℃ , The ultra-low temperature air-energy water heater runs stably for a long time in the environment of -26℃~43℃.

Product Usage of High Efficiency Air Source Heat Pump Water Heater
It is suitable for hot water supply in homes, schools, hospitals, hotels, SPA clubs and other occasions.

Performance characteristics
1. Adopt special compressor for heat pump, with high thermal efficiency and long life. The ultra-low temperature model is equipped with the quasi-two Yasuo jet enthalpy system to realize stable operation at -26℃.
2. The unique enhanced evaporator structure and high-efficiency piping system can effectively improve the winter energy efficiency ratio and reduce the frosting rate. With the intelligent heat pump defrosting system, it can ensure the energy efficiency of the heat pump in humid and low temperature.
3. Modular design, which can realize the joint control and remote monitoring of 16 units. Each unit has an independent frame structure, heating system, power distribution system, control system and protection function. When one of the units fails, it will not affect The normal operation of other units.
4. The advanced intelligent control system has comprehensive protection functions such as high pressure protection, low pressure protection, water shortage protection, leakage protection, phase loss protection, overload protection, antifreeze protection, and exhaust temperature overheat protection. It is convenient and simple to manage.


Specification of High Efficiency Air Source Heat Pump Water Heater

Triple supply parameters Cooling, heating and hot water functions
Side wind
Side wind)
Side wind
(Out of the wind)
Rated voltage 220V~50Hz 220V~50Hz 220V~50Hz 380V 3N~50Hz
Cooling and heating Nominal cooling
7.8kW(2kW-9kW) 13kW(3kW-15kW) 14.5kW(4kW-16.5kW) 14.5kW(4kW-16.5kW)
Nominal cooling power
2.77KW 4.6KW 5.27KW 5.27KW
Nominal cooling(COP) 2.81 2.82 2.75 2.75
IPLV 4.11 4.13 4.02 4.02
Nominal heating capacity 8.4kW(2.5kW-9.6kW) 14kW(3.5kW-16kW) 17kW(4.3kW-18.5kW) 17kW(2.5kW-18.5kW)
Nominal heating power
2.78KW 4.5KW 5.6KW 5.6KW
Heating Nominal heating capacity 6.8KW 10.5KW 13KW 13KW
Nominal heating
power consumption
1.75KW 2.65KW 3.3KW 3.3KW
Nominal heating(COP) 3.88 3.96 3.93 3.93
Maximum operating current 20A 33A 41A 21A
Maximum power consumption 4KW 6.6KW 7.9KW 7.9KW
Rated water flow 1.34m²/h 2.24m²/h 2.5m²/h 2.5m²/h
Refrigerant/charge volume R410A/1750g R410A/4000g R410A/4000g R410A/4800g
noise ≤54dB(A) ≤56dB(A) ≤57dB(A) ≤58dB(A)
Water resistance ≤14kPa ≤15kPa ≤21kPa ≤21kPa
Maximum working pressure on low
pressure/high pressure side
4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa
Allowable working pressure on
suction/exhaust side
4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa
Anti-shock level I I I I
waterproof level IPX4 IPX4 IPX4 IPX4
Unit size (l× w × h) 1030×410×865(mm) 1030×410×1390(mm) 1030×410×1390(mm) 820×780×1700(mm)
(Cold and warm) Caliber of inlet
and outlet
DN25 DN32 DN32 DN32
(Hot water) Caliber DN20 DN25 DN25 DN25


KCHR-8I/BP Side Wind All In One Heat Pump Water Heater 3.88 COP 0KCHR-8I/BP Side Wind All In One Heat Pump Water Heater 3.88 COP 1
