PRODUCT DESCRIPTION
Household All in One Air Source Heat Pump Heat Water OEM/ODM
• Intelligent flow channel, stable and efficient
• Using multi-variable microchannel technology and flexible bonding technology, the heat exchange area is
larger, the heat transfer effect is better, the system energy efficiency is higher; the heat exchanger does not
contact with the water in the water tank, no corrosion, scaling, leakage; the whole uses intelligent high- pressure foaming, the heat preservation layer is fine, uniform and compact, and the heat preservation effect
is better. The special protective liner made of Blue Gold Steel has passed 280,000 times of bearing pressure
pulse test and its performance is stable. • Innovation and technology, international quality
• Multi-variable program micro-channel Technology
• Blue Gold Steel special protective liner
• Australian Standard anti-fatigue pressure resistance
• corrosion resistance ultra-long life
• direct heat transfer heating fast without waiting
• Lasting heat preservation, environmental protection and energy conservation
Blue gold steel enamel liner
280,000 times of pulse pressure test, no leakage, No scaling, corrosion resistance, clean and healthy water quality
Efficient heat pump system, smart and energy saving
Special compressor for heat pump, fast heating, water temperature
High, energy-saving and stable system
Simple appearance, elegant and fashionable
Stylish square appearance design, suitable for all kinds of homes
Dress style, highlight the noble atmosphere
All-in-one design, easy installation
Small footprint, while saving space, Make installation easier and faster
Household All in One Air Source Heat Pump Heat Water OEM/ODM 80 to 500L space saving
Factory introduction
• Leomon is specialized in the research and development, production
and sales of new energy products such as enamel pressure water
tanks, solar energy, and air energy water heaters. • Supplier for many high-tech enterprises. Leomon continuously
innovates designs, obtains national patents, and possesses key
technologies. The company always insists on high quality
• The quality route is to create high-quality new energy products. The
products have passed the European Union CE, SOLAR KEYMARK,
North American ETL, Australia WATER MARK, British water and other
international certifications.
Specification of
Household All in One Air Source Heat Pump Heat Water OEM/ODM 80 to 500L space saving
| All in one heat pumps specification | ||||||
| Item | KRS16A-80H | KRS16A-100H | KRS37B-150V | KRS37B-200V | KRS37B-350V | KRS37B-420V |
| Rated Capacity | 80L | 100L | 150L | 200L | 350L | 420L |
| EER | 1 | |||||
| Energy efficiency ratio | 3.4 | 3.4 | 3.46 | 3.46 | 3.49 | 3.49 |
| Rated voltage/ frequency | 220V~50HZ | |||||
| Heating power | 750W | 750W | 1800W | 1800W | 5300 W | 5300 W |
| Heating capacity | 16L/h | 16L/h | 37L/h | 37L/h | 50L/h | 50L/h |
| Rated max water temperature | 75℃ | |||||
| Max input power | 2450W | 2450W | 2200W | 2200W | 5000W | 5000W |
| Heat pump rated power | 220W | 220W | 520W | 520W | 1300W | 1300W |
| Rated power of electric heating | 1500W | 1500W | 1500W | 1500W | 2500W | 2500W |
| Rated pressure of water tank | 0.8MPa | |||||
| noise | 45 dB(A) | |||||
| weight KG | 65 | 72 | 74 | 86 | 205 | 235 |
| Refrigerant | R22 | R22 | R22 | R22 | R134A | R134A |
| Working temperature | 5~45℃ | |||||
| Product dimensions mm | Φ470×1075 | Φ470×1225 | Φ525×1620 | Φ525×1950 | 675*937*1720 | 675*1006*1720 |
| Package dimensions mm | 550×520×1195 | 550×520×1345 | 590×590×1710 | 590×590×2045 | 715*960*1810 |
715*1080*1810
|
