50Hz ASHP Heating Air Source Heat Pump System 400KW Dc Powered Heat Pump
50Hz ASHP Heating Air Source Heat Pump System 400KW Dc Powered Heat Pump
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CE ISO CCC
Model Number: KCHR-15II/BP (Out of the wind)
High Light:

ASHP Air Source Heat Pump System


IPX4 dc powered heat pump


50Hz dc powered heat pump

Payment & Shipping Terms
Packaging Details: standard export package, or as per customer request
Delivery Time: 1-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000pcs/year
Power Range: 3.5-400KW
DHW Temperature: Up To 65°C When Cooling And 55°C When Heating
Energy Class: A++/A+
Supplementary Items: Thermal Solar System Or Water Heater Management
Operational Limits: -32°C --- 50°C
Usage: Conditioning And DHW With Air-water Heat Pump
Product Description

Strength of ASHP Heating Air Source Heat Pump System

Its is an inverter heat pump system for conditioning and for DHW production with heat recovery, offers various significant advantages that make this a complete, incredibly innovative, highly efficient, high quality product for conditioning residential or small service sector spaces and to produce domestic hot water.

The main advantages of the leomon heat pump are:

  • Fast and effective cooling
  • DHW production and heat recovery
  • Dehumidification
  • Ease of installation
  • Immediate heating through natural convection
  • Greater distance between outdoor unit and terminals
  • Maintenance free
  • System operation and simultaneous DHW production
  • Free DHW in summer


Leomon heat pumps introduction for Air To Water Heat Pumps Innovative Low-Energy HVAC Systems

Leader for air source heat pumps, decades experience,authorized over100 patents, leader for swimming pool air source heat pumps and other pumps, member for editing heat pumps field standards, strong and professional technical team


20 years of professional heat pump system technology excellence

We give full play to the advantages of scientific and technical personnel, and constantly overcome the technical bottlenecks in the field of air energy water heater. We have obtained 120 invention patents, more than 350 other patents, and participated in the preparation of 25 national standards.

Our strong and professional technical and marketing team ready to make best service!

Pre order(Inquiry progress):

Check with customer about usage, request specifications, enviroment and other request

Make details proposal/offer to customer

Order Processing

  • Machine installed and tested by QA engineers.

  • Ensure all the products we provide are qualified and new. The working life of the main engine is 15 years.

  • Construct and install the heat pump according to national relevant policies strictly and ensure high quality delivery on time.

  • Test and debug the equipments strictly to ensure the safety and stability.

  • During the delivery, provide comprehensive and professional technical training on instructions and maintenance to customers

  • After sale service

  • 2 years warranty

  • Feedback and solution will be provided within 1 working day

  • Free technical support!

  • Technical paremeters for Monoblock Split DC INVERTER SYSTEMS Smart Energy Solutions

  • Normal temperature Air source heat pumps
    Nominal heating capacity at room temperature(kW) 9.6 10.8 10.8 19 19 28 42.5
    Nominal input power at room temperature(kW) 2.17 2.7 2.7 4.19 4.19 6.2 9.2
    Rated voltage(Hz) 220V-50 220V-50 380V3N-50 220V-50 380V3N-50 380V3N-50 380V 3N-50
    Low temperature heating(kW) 7.8 8.8 8.8 15.5 15.5 23 34.5
    Low temperature input power(kW) 2.15 2.65 2.65 4.18 4.18 6.18 9.1
    Maximum input power(kW) 3 4.2 4.2 8 8 8 16
    Maximum current(A) 16 23 8 32 13 13 24.5
    noisedb(A) <55 <63 <63 <66 <66 <62 <63
    Anti-shock level I
    waterproof level IPX4 IPX4 IPX4 IPX4 IPX4 IPX4 IPX4
    Caliber of outlet DN20 DN20 DN20 DN32 DN32 DN32 DN40
    Unit size (mm) 1010x350x835 1030x410x865 1030x410x865 1030x410x1390 1030x410x1390 820x780x1700 1550x780x1700
    Unit Weight(kg) 84 88 88 126 126 260 400
  • 50Hz ASHP Heating Air Source Heat Pump System 400KW Dc Powered Heat Pump 0
  • 50Hz ASHP Heating Air Source Heat Pump System 400KW Dc Powered Heat Pump 1
  • 50Hz ASHP Heating Air Source Heat Pump System 400KW Dc Powered Heat Pump 2
