Strength of 200L Air Ducted Heat Pump All In One Domestic Water Heater
This heat pump is the latest generation of advanced products integrating central hot water, floor heating and other multi-purposes. Its working principle is based on the principle of reverse Carnot cycle, driving the compressor with a small amount of electricity, and sucking in low-temperature and low-pressure gaseous refrigerant from the evaporator. , Compressing it into high temperature and high pressure gas by doing work enters the condenser and exchanges transients with water. It is condensed into a low-temperature liquid in the condenser to release a large amount of transients. The water absorbs the heat released to increase the temperature, and the condensed After the low-temperature and high-pressure liquid is throttled and pressure-reduced by the expansion valve, it is absorbed by the surrounding air and evaporated into low-pressure gas by the fan in the evaporator, which is then sucked into the compressor and compressed for work. This cycle is repeated to produce the required hot water .
The whole process is an environmental (air/water source/underground) energy transfer process, without electric heating elements or burning combustible gas to heat hot water. It has the characteristics of high efficiency, energy saving and safety. It has only 25% of electric water heaters and 70% of gas water heaters and 35% of solar water heaters.
Leomon heat pumps introduction for 200L Air Ducted Heat Pump All In One Domestic Water Heater
Leader for air source heat pumps, decades experience,authorized over100 patents, leader for swimming pool air source heat pumps and other pumps, member for editing heat pumps field standards, strong and professional technical team
20 years of professional heat pump system technology excellence
We give full play to the advantages of scientific and technical personnel, and constantly overcome the technical bottlenecks in the field of air energy water heater. We have obtained 120 invention patents, more than 350 other patents, and participated in the preparation of 25 national standards.
Technical paremeters for Monobloc Air Source Water Heater All In One Heat Pump
| Low temperature hot water unit parameters | ||||
| Spec. | DKFXRS-11I/R | DKFXRS-11II/R | DKFXRS-16I/R | DKFXRS-16II/R |
| Nominal heating capacity at room temperature(kW) | 113 | 10.9 | 16 | 16.8 |
| Nominal heating at room temperature(kW) | 2.56 | 2.65 | 3.9 | 4.1 |
| Low-temperature nominal heating capacity(kW) |
4.8 | 4.75 | 7.9 | 8.1 |
| Low temperature nominal heating(kW) | 2.1 | 2.15 | 3.38 | 3.5 |
| Maximum input power(kW) | 4.2 | 4.2 | 6.6 | 6.8 |
| Maximum current(A) | 23 | 8 | 32 | 12 |
| Power Specifications(Hz) | 220V ~ 50 | 380V 3N ~ 50 | 220V ~ 50 | 380V 3N ~ 50 |
| Refrigerant/charge amount | R22/5600g | R22/5600g | R22/6000g | R22/6000g |
| noisedb(A) | <62 | <62 | <65 | <65 |
| Water resistancekPa | <55 | <55 | <100 | <100 |
| Anti-shock level | I | |||
| waterproof level | IPX4 | IPX4 | IPX4 | IPX4 |
| Caliber of inlet and outlet |
DN32 | DN32 | DN32 | DN32 |
| Unit size (mm) | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 |
| Unit Weight(kg) | 142 | 142 | 148 | 149 |
