R410A Split T3 Wall Mounted Air Conditioner 50Hz 60Hz For Hotel Outdoor
R410A Split T3 Wall Mounted Air Conditioner 50Hz 60Hz For Hotel Outdoor
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CE ISO CCC ROHS
Model Number: 1P
High Light:

T3 Wall Mounted Air Conditioner


R410A Wall Mounted Air Conditioner


60Hz Outdoor Split Air Conditioner

Payment & Shipping Terms
Packaging Details: standard export package, or as per customer request
Delivery Time: 1-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000pcs/year
Application: Hotel, Garage, Commercial, Household, For Home
Product Name:: Wall-mounted Air Conditioning
Heating Capacity:: 8871-24737BTU
Function: Single Or Both Cooling&Heating
Refrigerant:: R410a
Type: Split Wall Mounted Air Conditioners
Product Description

Features of R410A Refrigerant 50Hz 60Hz On-Off Type Mini Split T3 Wall Mounted Room Air Conditioner for Hotel,Outdoor,Househ

1.Vector Precision Air Supply,More choices for users.

2.Smart Airflow

3.Clean & Healthy:55℃ High Temperature Self-cleaningA evaporator that can clean itself

4. Low noise:Noise Reduction:A.Changing the angle of the air inlet airoutlet and volute tongue for betterheating and blowing.
B.Changing the bending angle of theevaporator to enlarge the heat exchangearea and reduce the resistance of wind,in order to improve heat exchange
C.High efficiency. 1~2 dB noise reduction of the whole airconditioner.


OEM/ODM service!


Specification for R410A Refrigerant 50Hz 60Hz On-Off Type Mini Split T3 Wall Mounted Room Air Conditioner for Hotel,Outdoor,Househ



Power souce 220-240V/50Hz-60Hz 220-240V/50Hz-60Hz 220-240V/50Hz-60Hz 220-240V/50Hz-60Hz 220-240V/50Hz-60Hz 220-240V/50Hz-60Hz
Horsepower(P) 1 1.5 2 3 3.5 4
Capacity (BTU) 9000BTU 12000BTU 18000BTU 24000BTU 30000BTU 36000BTU
Cooling capacity 2500W 3496W 5100W 7200W 7600W 8800W
Cooling powet input 820W 1160W 1650W 2200W 2450W 3220W
Heating capacity 2550W 3530W 5000W 7000W 7700W 9000W
Heating powet input 860W 1230W 1600W 2100W 2250W 3100W
Current input 4.2A 5.9A 7.8A 9.8A 11.5A 13.8A
Air Flow Volume(M3/h) 450 550 900 950 1350 1500
Ratde current input 5.9A 7.9A 12.3A 13 18.5A 21A
Indoor/Ourdoor noise 30~36/45db(A) 36~42/48db(A) 39~45/55db(A) 42~46/55db(A) 46~51/56db(A) 48~53/58db(A)
Refrigerants R22/520g R410/860g R410A/1500g R410A/1650g R410A/2130g R410A/2590g
Pipe diameter 6.35 / 9.52 6.35 / 12.7 6.35 / 12.7 9.52 / 15.88 9.52 / 15.88 9.52 / 15.88
Weight 9/29KG 11/35KG 13/43KG 14/54KG 18/58KG 20/72KG
Product Dimensions
Indoor unit 790*280*200 790*280*200 890*300*210 1020*320*260 1180*330*280 1320*350*290
Outdoor unit 600*250*450 780*260*550 850*300*600 850*320*700 850*320*700 900*320*860
Packing Dimensions
Indoor unit 865*330*260 870*350*275 980*370*300 1100*390*320 1350*400*330 1480*420*360
Outdoor unit 760*350*550 860*350*600 950*400*680 990*400*690 990*400*750 1120*500*900
Quantities 20GP(28m³) 126 units 105 units 75 units 68 units 58 units 38 units
40HQ(68m³) 308 units 258 units 185 units 165 units 140 units 90 units

Q:Are you a manufacturer or trading company for 60HZ 12000BTU 24000BTU R410A Refrigerant wholesalers industrial split inverter air conditioner domestic and commercial?
A:We are a manufacturer that specialized in refrigeration equipment. Our products have abtained the CE.
Q: What kind of delivery for the product?
A: We can arrange the shipping by sea or by air.
Q: How is your after-sales service?
A: All the product is guarantee for one year.And we will supply the technical support after the warranty time. You can contact us 24 hours each day online.
Q:How can I get some samples?
A: We welcome sample order to test and check quality. We can’t offer free sample, please pay the sample and express fee.
Q: How about the packing?
A: packed in carton, can customized different logo according to customers' requirements.
If you have any other questions,you can leave us message or inquiry then we will contact you. Or you can directly call us or
sendus direct mail or fax to consult us.
