Leomon heat pump energy-saving low-temperature heat pump water heater includes a low-temperature heat pump unit, a heater, and a diverter valve. One end of the heater is rotatably connected with an inlet pipe, one end of the inlet pipe is rotatably connected with a diverter valve, and the diverter valve is input A connecting pipe is welded and communicated with the outlet, a drainage pipe is welded and communicated with the water outlet of the diverter valve, one end of the pipe is snap-connected with the water outlet of the low-temperature heat pump unit, and the top of the low-temperature heat pump unit is welded with a heat preservation water tank. It is convenient to convert solar energy into electric energy to supply heaters and low-temperature heat pump units, which saves energy consumption. Through the installation of heat preservation water tanks and solar hot water pipes, it is convenient to absorb solar heat to initially heat water at room temperature, thereby reducing low-temperature heat pump The time for the unit to heat the water at room temperature saves the energy consumption of the low-temperature heat pump unit, thereby saving the energy consumption of the hot water machine
| Spec. | DKFXRS-9I/CY | DKFXRS-11I/CY | DKFXRS-11II/CY | DKFXRS-16I/CY |
| Nominal heating at room temperature・(kW) | 9.6 | 10.9 | 10.8 | 16 |
| Nominal power consumption at room temperature(kW〕 | 2.17 | 2.63 | 2.7 | 3.9 |
| Low temperature heating(kW) | 4.1 | 4.65 | 4.8 | 7.8 |
| Low temperature power consumption(kW) | 1.85 | 2.1 | 2.16 | 3.37 |
| Maximum input power(kW) | 3 | 4.2 | 4.2 | 6.6 |
| Maximum current(A) | 16 | 23 | 8A | 32 |
| Power Spec.(Hz) | 220V-50 | 220V-50 | 380V3N-50 | 220V-50 |
| Refrigerant/charge amount | R22/2500g | R22/5600g | R22/5600g | R22/6000g |
| noisedb(A) | <55 | <62 | <62 | <65 |
| Water resistancekPa | <55 | <55 | <55 | <100 |
| Anti-shock level | I | I | I | I |
| waterproof level | IPX4 | IPX4 | IPX4 | IPX4 |
| Circulation port diameter | DN20 | DN32 | DN32 | DN32 |
| Unit size (mm) | 1010x350x835 | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 |
| Unit Weight(kg) | 87 | 142 | 142 | 148 |
| Spec. | DKFXRS-16II/CY | DKFXRS-19II/CY | DKFXRS-38II/CY |
| Nominal heating at room temperature・(kW) | 16.4 | 17.4 | 38.9 |
| Nominal power consumption at room temperature(kW〕 | 4.1 | 4.6 | 8.82 |
| Low temperature heating(kW) | 7.5 | 8.5 | 17.6 |
| Low temperature power consumption(kW) | 3.4 | 3.68 | 7.3 |
| Maximum input power(kW) | 6.8 | 8.5 | 17 |
| Maximum current(A) | 12 | 15 | 30 |
| Power Spec.(Hz) | 380V 3N-50 | 380V3N-50 | 380V 3N-50 |
| Refrigerant/charge amount | R22/6000g | R22/6500g | R22/6500gx2 |
| noisedb(A) | <65 | <66 | <68 |
| Water resistancekPa | £100 | <65 | <65 |
| Anti-shock level | I | I | I |
| waterproof level | IPX4 | IPX4 | IPX4 |
| Circulation port diameter | DN32 | DN32 | DN40 |
| Unit size (mm) | 1030x410x1390 | 780x820x1700 | 1550x780x1700 |
| Unit Weight(kg) | 149 | 265 | 435 |
FAQ:
| Q1 | How about your delivery time ? |
| A1 | Generally, it will take 1 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. |
| Q2 | What is your term of delivery ? |
| A2 | EXW, FOB, CIF, etc |
| Q3 | What is your terms of packing? |
| A3 | Generally, we pack the heat pump in brown cartons or plywood. If you have legally registered patent, we can pack the heat pump in your branded boxes after getting your authorization letters. |
| Q4 | What is your sample policy? |
| A4 | We accept the sample order, but the customers have to pay the sample cost and the courier cost. |
| Q5 | Do you test all your goods before delivery? |
| A5 | Yes, we have 100% test before we pack the goods for delivery |
| Q6 | How long is the guarantee time? |
| A6 | 2 years warranty on the whole unit. The spare parts must be non-humanly damaged, usually we give to customer 1% spare parts free of charge for maintenance according to order cost during the warranty period. |
