16KW Air Source EVI Electric Heat Pump With Intelligent Automatic Defrosting
negotiable
MOQ
Negotiable
Price
16KW Air Source EVI Electric Heat Pump With Intelligent Automatic Defrosting
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CB, CE, EMC, RoHS
Model Number: KCHR-8I/BP Side wind
High Light:

16KW electric heat pump

,

DHW Defrosting electric heat pumps

,

EVI Electric Heat Pump

Payment & Shipping Terms
Packaging Details: export package Woonden case or plastic film
Delivery Time: 1-30 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50,000pcs/year
Specifications
Defrosting: Intelgient Automatic Defrosting
Working Ambient Temperature: -30-50℃
After Sale Service: Free Spares
Power Ranges: 10-200KW
Low Noise & Vibration: ≤60db(A)
Application: Outdoor, Hotel, Commercial, Household, Hot Water
Product Description

Decades experience, strong technical and commercial team, over 300 patents, Leomon Technlogy plays top role in producing and supplying heat pumps

Leomon developed a patent of  heat pump relates to the field of ultra-low temperature air energy heat pump intelligent automatic defrosting technology. It discloses an ultra-low temperature air energy heat pump intelligent automatic defrosting system. The second electrical conductor includes a copper block, a spring, a copper sheet, an insulating sleeve, Live contact, neutral contact and copper plate, the surface of one end of the copper block is fixedly connected to the inner wall of the insulating sleeve through a spring, one end of the insulating sleeve is fixedly connected to one end of the live contact, and one end of the live contact is fixed to one end of the copper sheet Connection, the copper sheet is located inside the insulating sleeve, one end of the live wire contact is fixedly installed on the side of the glass container, the other end of the neutral contact is fixedly connected to one end of the wire, and the other end of the live wire contact is fixedly connected to the other end of the wire , The bottom of the joint is fixedly connected with the fan, the surface of the fan is fixedly connected with one end of the steel pipe through the bracket, and the fan blade is fixedly installed on the output shaft of the fan. The utility model achieves the effect of intelligent and energy-saving defrosting

The ultra-low temperature air source heat pump adopts an ultra-low temperature compressor commonly used in cold regions of Europe and a low-temperature high-efficiency environmentally friendly refrigeration system 410A. The heating energy efficiency at low temperature (-25℃) is 50%-80% higher than that of conventional air source heat pump units. Ultra-low temperature air When the ambient temperature drops sharply, the heat attenuation of the source heat pump unit is very small, and the heating effect is fully guaranteed. The user generally uses the room heating and domestic hot water in the cold winter area. Its energy-saving effect is obvious, which is about other heating heating. The cost of equipment is 1/3, and it is the primary choice for the trinity of heating, cooling and domestic hot water in homes, communities, hotels, guesthouses, villas and other places

Features:
1. Twin rotary compressor with inverter control - DC inverter technology control the heat pump output according to the household's energy requirements. Low waste of the power.
2. R410A refrigerant, environmentally friendly.
3. Intelligent controller and LCD display.
4. Safety operation with multi-protections.
5. Electronic Expansion Value control accurate refrigerant to ensure the heat pump can work with high efficiency performance in any conditions.
6. Hydrophilic coating air exchanger and SS316 plate heat exchanger all available.
7. Auto defrosting function.
8. Convenient for installation and maintenance.

Spec. DKFXRS-11I/R DKFXRS-11II/R DKFXRS-16I/R DKFXRS-16II/R
Nominal heating capacity at room temperature(kW) 11.3 10.9 16 16.8
Nominal heating at room temperature(kW) 2.56 2.65 3.9 4.1
Low-temperature
nominal heating
capacity(kW)
4.8 4.75 7.9 8.1
Low temperature nominal heating(kW) 2.1 2.15 3.38 3.5
Maximum input power(kW) 4.2 4.2 6.6 6.8
Maximum current(A) 23 8 32 12
Power Specifications(Hz) 220V ~ 50 380V 3N ~ 50 220V ~ 50 380V 3N ~ 50
Refrigerant/charge amount R22/5600g R22/5600g R22/6000g R22/6000g
noisedb(A) <62 <62 <65 <65
Water resistancekPa <55 <55 <100 <100
Anti-shock level I
waterproof level IPX4 IPX4 IPX4 IPX4
Caliber of inlet
and outlet
DN32 DN32 DN32 DN32
Unit size (mm) 1030x410x1390 1030x410x1390 1030x410x1390 1030x410x1390
Unit Weight(kg) 142 142 148 149



Spec. DKFXRS-19II/R DKFXRS-38II/R DKFXRS-95II/R DKFXRS-190II/R
Nominal heating capacity at room temperature(kW) 18.6 38.8 90 190
Nominal heating at room temperature(kW) 4.5 8.8 19.5 43
Low-temperature
nominal heating
capacity(kW)
8.6 17.7 42 84
Low temperature nominal heating(kW) 3.7 7.35 16.3 32.6
Maximum input power(kW) 8.3 17 40 80
Maximum current(A) 15 30 88 176
Power Specifications(Hz) 380V3N ~ 50 380V3N ~ 50 380V 3N ~ 50 380V 3N ~ 50
Refrigerant/charge amount R22/6500g R22/6700gx2 R410A/8500gX2 R410A/8500gX4
noisedb(A) <66 <68 <78 <81
Water resistancekPa <100 <100 <100 <123
Anti-shock level I
waterproof level IPX4 IPX4 IPX4 IPX4
Caliber of inlet
and outlet
DN32 DN40 DN50 DN75
Unit size (mm) 780x820x1700 1550x780x1700 2206x1030x2170 2206x2020x2170
Unit Weight(kg) 263 431 750 1200

16KW Air Source EVI Electric Heat Pump With Intelligent Automatic Defrosting 0

16KW Air Source EVI Electric Heat Pump With Intelligent Automatic Defrosting 1





16KW Air Source EVI Electric Heat Pump With Intelligent Automatic Defrosting 2

FAQ:

Q1.What does Leomon Technology do and strength?
A:Leomon Technology is a professional manufacturer enjoy over 20 years experience in refrigeration and heating industry. We are leader member and as mainly manager for edditing several air source heat pumps standard. Over 300 patents, our heat pumps are widely used for villas, buildings, commercial buildings, etc



Q2. What is your product series and application?

A: We make full range heat pump products involving air to water heat pump, water to water heat pump ,heat pump drier , industrial water cooled chiller ,swimming pool heat pump and some other relative products . Used for swimming pool, spa, buildings, household, cold places, for heating, cooling, hot water(DHW)



Q3. I am not professional, how do i choose?
A: We have professional technical team, we can offer you plan, just need to tell your application.

Q4. How about the delivery time?
A: If stock, can delivery same day

Q5. What is the MOQ ?
A: You can order even 1 pc, no MOQ request

Q6. OEM order is ok ?
A: Yes. OEM brand is accepted. Please provide your logo and brand authorization to us before production .

Q7: What's the warranty time?

A: 24 month.

Q8. What about quality control?

A:  3C certification, 100% products inspection, free spares supply, free technical support for customers!



Welcome to contact!
