16KW Air Source EVI Monoblock Air To Water Heat Pump Inverter Ultra-Low Temperature - Commercial water heater 15P
Function of ultra-low temperature hot water machine:
hot water ultra-low temperature heat pump series, the water temperature of the unit during operation in a cycle of 3-5C, so repeated cycle, until the water temperature reaches the set temperature (55"C). Hot water ultra-low temperature series can be used at the lowest ambient temperature of 30℃ above, the most productive water temperature of 60℃,
Applicable places 16KW Air Source EVI Monoblock Air To Water Heat Pump Inverter Ultra-low temperature - commercial water heater 15P:widely used in hotels, schools, hospitals, factories, hot springs, saunas, spa health centers and other places that need hot water.
What are the factors that affect the power consumption of the air energy hot water integrated machine?
(1) Fixed frequency and variable frequency
In the past, fixed-frequency air had a fixed frequency. Therefore, in a low-temperature environment, the effect is relatively inferior to that of frequency conversion, and it also has to constantly defrost. However, the variable frequency air can be adjusted automatically when it is working, and when the long high frequency is adjusted during defrosting, the defrosting time will be reduced and the heat control will be greatly improved. Therefore, when the ambient temperature is particularly low, the energy-saving advantages of frequency conversion are greatly highlighted.
(2) Problems with installation
As the so-called seven points depend on installation, three points depend on the product. Especially for the air-energy and hot water integrated machine, the installation work is particularly important. It is an important factor that affects the number of kilowatt-hours a day for the air energy and hot water integrated machine, such as pipelines. Model selection, water pump installation, etc. will affect the power consumption of the air-energy hot water integrated machine.
(3) Differences in usage habits
There are clear regulations for the indoor heating temperature, which is generally around 18 degrees Celsius, so many users set it at 20 degrees, but there are also many users who set it higher, which will be around 25 degrees Celsius. The higher the temperature is adjusted, the more power consumption will be. The air energy and hot water integrated machine can modulate the specific temperature of different rooms. If the family is not at home, the water temperature can be lowered a bit, which can save a lot of costs.
Some technical paremeters for 16KW Air Source EVI Monoblock Air To Water Heat Pump Inverter Ultra-Low Temperature - Commercial Water Heater 15P
Spec. | DKFXRS-9I/CY | DKFXRS-11I/CY | DKFXRS-11II/CY | DKFXRS-16I/CY | DKFXRS-16II/CY | DKFXRS-19II/CY | DKFXRS-38II/CY |
Nominal heating at room temperature・(kW) | 9.6 | 10.9 | 10.8 | 16 | 16.4 | 17.4 | 38.9 |
Nominal power consumption at room temperature(kW〕 | 2.17 | 2.63 | 2.7 | 3.9 | 4.1 | 4.6 | 8.82 |
Low temperature heating(kW) | 4.1 | 4.65 | 4.8 | 7.8 | 7.5 | 8.5 | 17.6 |
Low temperature power consumption(kW) | 1.85 | 2.1 | 2.16 | 3.37 | 3.4 | 3.68 | 7.3 |
Maximum input power(kW) | 3 | 4.2 | 4.2 | 6.6 | 6.8 | 8.5 | 17 |
Maximum current(A) | 16 | 23 | 8A | 32 | 12 | 15 | 30 |
Power Spec.(Hz) | 220V-50 | 220V-50 | 380V3N-50 | 220V-50 | 380V 3N-50 | 380V3N-50 | 380V 3N-50 |
Refrigerant/charge amount | R22/2500g | R22/5600g | R22/5600g | R22/6000g | R22/6000g | R22/6500g | R22/6500gx2 |
noisedb(A) | <45 | ||||||
Water resistancekPa | <55 | <55 | <55 | <100 | £100 | <65 | <65 |
Anti-shock level | I | I | I | I | I | I | I |
waterproof level | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 |
Circulation port diameter | DN20 | DN32 | DN32 | DN32 | DN32 | DN32 | DN40 |
Unit size (mm) | 1010x350x835 | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 | 780x820x1700 | 1550x780x1700 |
Unit Weight(kg) | 87 | 142 | 142 | 148 | 149 | 265 | 435 |
