The utility model adopts a water tank cold and hot water layering device, which belongs to the field of water tank fluid electric heating. The utility model comprises a main machine and a water tank body, a circulating port a joint and a circulating port B joint are arranged under the side of the water tank body, the circulating port a joint and the circulating port B joint are respectively connected with the main machine through a water pipeline connecting pipe, the circulating port B joint is higher than the circulating port a joint, a fixed bracket is arranged above the circulating port B joint, which is fixed on the inner wall of the water tank with bolts, and the fixed support A water inlet distributor is fixedly arranged on the frame, and the water inlet distributor is connected with the circulating port B joint, and a plurality of holes are uniformly distributed on the water inlet distributor. The utility model can realize that when the user uses the hot water, the cold water can be evenly distributed on the horizontal plane at the bottom of the water tank, forcing the hot water to lift up, so as to make the cold and hot water in the water phase layered, so that the user can use the hot water in the water tank to the maximum extent, thus playing the role of saving resources
Leomon heat pumps The utility model adopts a hot water control system of pressure module with multiple composite energy sources, including an air source heat pump water heater, a solar collector plate, an electric heating pipe, a pressure module heating water tank, a first pressure module heat storage water tank and a second pressure module heat storage water tank It is equipped with air source circulating water pump. By installing air source heat pump water heater, electric heating tube and solar collector tube in the system, the air energy, solar energy and electric energy can be combined into a heating system. If there is a large demand for hot water, the control system can also use air energy, solar energy and electric energy to generate a large amount of hot water. This system can not only produce a large number of hot water, but also has a good energy-saving effect. It has a high degree of intelligence, and can adapt to different needs and changes in a variety of environments
Leomon heat pumps patent technology of parts monoblock, flexible installing, users can install everywhere convienient
| Spec. | KRY-8II | KRY-12II | KRY-24II | KRY-48II | KRY-96II | KRY-145II | KRY-220II |
| Rated heating capacity(A24/26oC) | 8kw | 12kw | 24kw | 48kw | 96kw | 145kw | 220kw |
| Rated power(kW) | 1.56 | 2.35 | 4.7 | 9.3 | 18.5 | 23.6 | 42.5 |
| COP | 5.1 | 5.1 | 5.1 | 5.16 | 5.41 | 6.14 | 5.17 |
| Rated heating capacityA20/26oC | 7.5kw | 11kw | 21kw | 44 kw | 90kw | 138kw | 208kw |
| Rated power(kW) | 1..5 | 2.3 | 4.5 | 8.6 | 17.5 | 24.1 | 41.5 |
| COP | 5 | 4.78 | 4.66 | 5.11 | 5.14 | 5.73 | 5 |
| Cooling Capacity(kW) | 3.8 | 5.7 | 11.3 | 23.7 | 40 | 58.1 | 98 |
| Consumed Power(kW) | 1.67 | 2.5 | 4.9 | 9.1 | 18.2 | 24.2 | 39 |
| EER | 2.3 | 2.3 | 2.3 | 2.6 | 2.2 | 2.4 | 2.5 |
| Rated voltage(Hz) | 220V 50HZ | 220V 50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 2 | 3 | 6 | 12 | 24 | 36.5 | 61 |
| Maximum current(A) | 8 | 12 | 24 | 42 | 80 | 90 | 130 |
| Water flownWh | 2.3 | 3.5 | 7 | 13 | 32 | 41 | 62 |
| noise dB(A) | <50 | <50 | <65 | <68 | <69 | <71 | <73 |
| Anti-shock level | I | I | I | I | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 910x350x835 | 1030x410x865 | 780x820x1700 | 1550x780x1700 | 1550x1550x1700 | 2360x1550x1840 | 2206x2020x2170 |
| Unit Weight(kg) | 65 | 95 | 260 | 380 | 760 | 2100 | 4005 |
.
FAQ:
Q: What is your strength in heat pump industry?
A: Decades experience in the field of heat pumps for more than 19 years. Over 300 patents, leader member for ediiting heat pumps standard.
Q: Do you accept OEM & ODM?
A: Yes. We can supply products under clients' brand, modify the products to satisfy client's personalized requirements and work together with clients to design and produce a totally new products.
Q: What support do you offer to clients?
A: We can: provide product certification requirements for local markets; provide catalogs, technical manuals; co-exhibit with the clients in leading industry exhibitions; do promotion on the local market’s media by our news release resources.
Q: Could I have a sample to check the quality ?
A:Yes, sample order is okay.If the model in stock, we even can ship immediately.
Q:Why is air to water heat pump a recommended heating solution?
A:Using renewable energy reduces your environmental impact while allowing you to save money. A correctly installed air to water heat pump system that is specific to your home's dimension lowers your heating costs by up to 50%.
Welome to contact us For the most suitable Heating,Cooling,Hot Water Solution!
