| MOQ: | negotiable |
| Price: | Negotiable |
| Standard Packaging: | export package Woonden case or plastic film |
| Delivery Period: | 1-30 days |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Capacity: | 50,000pcs/year |
This energy-saving air energy heat pump water supply device is adopted, including a first water tank, a second water tank, an air energy heat pump, a circulating water pump, and a filter. The first water tank is connected to the air energy heat pump, and the right side of the air energy heat pump is also fixed. A second water tank is provided; the top of the air energy heat pump is fixedly provided with a circulating water pump, the suction port of the circulating water pump is connected with the heat exchanger of the air energy heat pump through a water pipe, and the drain is connected with the filter. The structure of the utility model is reasonable in design. By first heating the water with higher temperature and liquid level, the heat exchange rate can be increased, energy can be saved, and the working efficiency of the equipment can be effectively improved. The filter can effectively filter impurities such as scale in the water. Improve water quality; and through the probe and control valve, it can effectively avoid serious damage to equipment due to abnormal high and low pressure.
| Constant temperature swimming pool heat pump | ||||
| Spec. | KRY-8II | KRY-12II | KRY-24II | KRY-48II |
| Rated heating capacity(A24/26oC) | 8kw | 12kw | 24kw | 48kw |
| Rated power(kW) | 1.56 | 2.35 | 4.7 | 9.3 |
| COP | 5.1 | 5.1 | 5.1 | 5.16 |
| Rated heating capacityA20/26oC | 7.5kw | 11kw | 21kw | 44 kw |
| Rated power(kW) | 1..5 | 2.3 | 4.5 | 8.6 |
| COP | 5 | 4.78 | 4.66 | 5.11 |
| Cooling Capacity(kW) | 3.8 | 5.7 | 11.3 | 23.7 |
| Consumed Power(kW) | 1.67 | 2.5 | 4.9 | 9.1 |
| EER | 2.3 | 2.3 | 2.3 | 2.6 |
| Rated voltage(Hz) | 220V 50HZ | 220V 50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 2 | 3 | 6 | 12 |
| Maximum current(A) | 8 | 12 | 24 | 42 |
| Water flownWh | 2.3 | 3.5 | 7 | 13 |
| noise dB(A) | <50 | <50 | <65 | <68 |
| Anti-shock level | I | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 910x350x835 | 1030x410x865 | 780x820x1700 | 1550x780x1700 |
| Unit Weight(kg) | 65 | 95 | 260 | 380 |
| Constant temperature swimming pool heat pump | |||
| Spec. | KRY-96II | KRY-145II | KRY-220II |
| Rated heating capacity(A24/26oC) | 96kw | 145kw | 220kw |
| Rated power(kW) | 18.5 | 23.6 | 42.5 |
| COP | 5.41 | 6.14 | 5.17 |
| Rated heating capacityA20/26oC | 90kw | 138kw | 208kw |
| Rated power(kW) | 17.5 | 24.1 | 41.5 |
| COP | 5.14 | 5.73 | 5 |
| Cooling Capacity(kW) | 40 | 58.1 | 98 |
| Consumed Power(kW) | 18.2 | 24.2 | 39 |
| EER | 2.2 | 2.4 | 2.5 |
| Rated voltage(Hz) | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 24 | 36.5 | 61 |
| Maximum current(A) | 80 | 90 | 130 |
| Water flownWh | 32 | 41 | 62 |
| noise dB(A) | <69 | <71 | <73 |
| Anti-shock level | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 1550x1550x1700 | 2360x1550x1840 | 2206x2020x2170 |
| Unit Weight(kg) | 760 | 2100 | 4005 |
FAQ:
| Q1 | How about your delivery time ? |
| A1 | Generally, it will take 1 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. |
| Q2 | What is your term of delivery ? |
| A2 | EXW, FOB, CIF, etc |
| Q3 | What is your terms of packing? |
| A3 | Generally, we pack the heat pump in brown cartons or plywood. If you have legally registered patent, we can pack the heat pump in your branded boxes after getting your authorization letters. |
| Q4 | What is your sample policy? |
| A4 | We accept the sample order, but the customers have to pay the sample cost and the courier cost. |
| Q5 | Do you test all your goods before delivery? |
| A5 | Yes, we have 100% test before we pack the goods for delivery |
| Q6 | How long is the guarantee time? |
| A6 | 2 years warranty on the whole unit. The spare parts must be non-humanly damaged, usually we give to customer 1% spare parts free of charge for maintenance according to order cost during the warranty period. |
