Description of Residential Air To Water Air Source Heat Pump Underfloor/Central Heating And Air Conditioning
Function
1.UnderFloor Radient Heating, air conditioner
2. Cooling
3. Hot water
Feature
Heating & cooling heat pumps are a smart, efficient way to heat and cool houses or commercial buildings. they function as an air conditioner in summer and a heater in winter. In addition to its flexibility, these heat pumps are energy-efficient too. Enjoy a comfortable environment and save energy with multifunctional heat pumps.
Application
1. Apartment
2. House
3. Villa
4. Factory
5. Hotel
6. School
7. Hospital
8. Commercial building
Advantage
1. Adopted with world-famous brand(Copeland) compressor and other components.
2. Durable, reliable, quiet, and efficient.
3. Intelligent remote wifi control offers comfortable heating or cooling.
4. Three temperature control
Real-time detection of water temperature
Leomon air source heat pumps air energy tank adopts three-point temperature control technology, which can monitor the water temperature in real time to ensure that the hot water is ready to use.
Modular control system to reduce energy loss
Provide moderate energy demand according to the end to reduce energy loss
Dual working conditions wide-frequency diversion technology to extend the life of the unit
Combining temperature compensation technology to ensure that the compressor reaches the best working condition under temperature changes, prolong the service life and improve work efficiency
Integration of main engine accessories
Improve installation efficiency and energy efficiency
In the strategic deployment of "integration of main engine accessories" for Leomon air source heat pumps floor heating air conditioners and ultra-low temperature heating machines, hydraulic balancer and floor heating air conditioners integrator have been released to reduce the installation threshold and installation faults, save installation time, and improve the quality of the whole machine and the energy efficiency of the system.
The host does not contain electric auxiliary heating, energy saving and electricity saving
All hosts do not contain electric auxiliary heat, which saves necessary operating costs
Efficient heating
SCL heat transfer technology
SCL technology has high heat transfer efficiency. Adopts metal coating to prevent scaling and withstand pressure up to 30KG. Specially used in air energy products, it is an alternative product for stainless steel plate and tube type heat exchanger.
OEM/ODM Service Residential Air To Water Air Source Heat Pump Underfloor/Central Heating And Air Conditioning
1. Galvanized steel or 304 stainless steel cabinet is optional.
2. Grey, white, black and other color is optional.
3. Heating function, cooling function, and hot water function are optional.
4. OEM brand name is optional.
5. ODM cabinet is optional.
6. Other power supplies (110V, 60Hz) are optional.
Company introduction
Decades production experience, its own labotory, over 380patents, norminated supplier for buildings, leader member for ediiting air source heat pumps standard, about 80000pcs air to water heat pumps production capacity a year!
Quality control:
100% inspection for each product, 3 phrases test before delivery, free spares supply, good prize if found any unqualified items
Production line:
3 production lines to guarantee production capacity and quick delivery, 2 shifts working
Technical paremeters of Residential Home Use Split Monoblock Air Source Heat Pump Water Heater 100L-500L
| Item | KFXRS-7I |
| Nominal heating capacity at room temperature(kW) | 7.2 |
| Nominal input power at room temperature(kW) |
1.63 |
| Rated voltage(Hz) | 220V-50 |
| Low temperature nominal heatingWkW) |
5.9 |
| Low temperature nominal input power(kW) |
1.62 |
| Maximum input power(kW) | 2.5 |
| Maximum current(A) | 11.5 |
| noisedb(A) | <51 |
| Anti-shock level | I |
| waterproof level | IPX4 |
| Caliber of inlet and outlet | DN20 |
| Unit size (mm) | 1010x350x835 |
| Unit Weight kg) | 72 |
| Item | KFXRS-28II |
| Nominal heating capacity at room temperature(kW) |
28 |
| Nominal input power at room temperature(kW) |
6.2 |
| Rated voltage(Hz) | 380V3N-50 |
| Low temperature nominal heatingWkW) |
23 |
| Low temperature nominal input power(kW) |
6.18 |
| Maximum input power(kW) | 8 |
| Maximum current(A) | 13 |
| noisedb(A) | <62 |
| Anti-shock level | I |
| waterproof level | IPX4 |
| Caliber of inlet and outlet | DN32 |
| Unit size (mm) | 820x780x1700 |
| Unit Weight kg) | 260 |
The nominal working conditions at room temperature are: ambient dry bulb 20°C, ambient wet bulb 15°C, initial water temperature 15°C, and ending water temperature 55.
(2; The nominal low temperature conditions are: ambient dry bulb 72, ambient wet bulb 61, initial water temperature 15°C, and ending water temperature 55℃.
