DC Inverter Split System Heat Pump IPX4 Heat Pump Heating And Cooling System
Negotiable
MOQ
Negotiable
Price
DC Inverter Split System Heat Pump IPX4 Heat Pump Heating And Cooling System
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CE ISO CCC
Model Number: DKFXRS-9I/CY
High Light:

ISO 500L Split System Heat Pump

,

IPX4 heat pump heating and cooling system

,

50Hz heat pump heating and cooling system

Payment & Shipping Terms
Packaging Details: standard export package, or as per customer request
Delivery Time: 1-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000pcs/year
Specifications
Outdoor Temp. Opera: Min:-15C/ Max: 60C
Compressor Type: Scroll
Housing Material: Gavanized Steel Or Stainless Steel
Defrosting: Fast Automatic Defrosting
Application:: Outdoor, Hotel, Commercial, Household, Bathroom House Hotel
Water Tank: 1-500 L, Free To Wash Whole Lifespan
Product Description

DC Inverter Split Heating&Cooling Air Source Heat Pump, -25 Degree Low Temperature Heat Pump



We are considering A solar heat pump and ground source heat pump combined air conditioning system and control method, comprising a solar heat collection unit, a heat pump host unit, an underground heat exchanger unit, an indoor terminal unit and a control unit, the solar heat collection unit and the underground heat exchanger unit , The indoor terminal unit is respectively connected with the heat pump main unit, and the control unit is respectively connected with the heat pump main unit, the underground heat exchanger unit and the indoor terminal unit. Through the above method, the present invention can realize heating in winter and cooling in summer. The solar heat pump heating mode is turned on during sunny days in winter, and the excess heat is stored in underground soil when the solar radiation intensity is sufficient; the ground source heat pump heating mode is turned on on cloudy and rainy days in winter and at night. , The ground source heat pump cooling mode is turned on in summer, and the energy storage mode is turned on during the transitional seasons of spring and autumn. The air-conditioning system always maintains efficient operation and continuous heating or cooling, saving energy to the greatest extent and keeping the underground temperature field balanced.


Strength of Leomon air to water heat pumps DC Inverter Split Heating&Cooling Air Source Heat Pump, -25 Degree Low Temperature Heat Pump
More comfortale:
Water is used as the air-conditioning medium, the temperature of the air outlet of the fan is 13-15℃, and the relative humidity is 30%-45%, which effectively maintains the temperature environment;
Energy saving
The main engine is controlled by frequency conversion. When the internal machine is running at low load, part of the main engine works, which is highly efficient and energy-saving; the secondary system design is adopted, and the end water pump is controlled by frequency conversion. When the use area is small, the pump runs at low frequency, which can greatly reduce the energy consumption of the pump. Loss; the water system is more energy efficient than the fluorine system by 20%.
More reliable
The indoor unit is only a simple heat exchange function. The two are independent of each other and do not affect each other. The indoor unit or the outdoor unit can be maintained separately; multiple hosts are independently designed. If one system fails or has a problem, other systems can still be used.
Easy maintenance
Using water as the refrigerant carrier makes leakage easy to detect and convenient for maintenance as soon as possible. The internal unit of the air source heat pump adopts a fan coil unit, which is versatile and easy to replace. The fan coil unit is controlled by an independent indoor temperature control, and the high efficiency is simple.
The air source heat pump is easy to maintain in the later period and the cost is low
Safety
Low-pressure water system leakage is extremely unlikely, even if the leakage is very obvious, it is harmless to the human body

Company brief introduction
Over 20 years production experience, thanks to R&D hard and smart working, company is authorized over 400 patents, products quality play a lead role in HVAC system field
Over 20% sales volume are invested on improving products research and company service imporovement, we are happy to say"We cannot promise that equipment won't break, that software won't fail, or that we will always be perfect. What we can promise is that if something goes wrong, we will rise to the occasion, take action, and help resolve the issue, and the most important is we have abilidty to solve! ."

Some technical paremeters for DC Inverter Split Heating&Cooling Air Source Heat Pump, -25 Degree Low Temperature Heat Pump

Item KCHR-8I/BP
Side wind
KCHR-13I/BP
Side wind)
KCHR-15I/BP
Side wind
KCHR-15II/BP
(Out of the wind)
Rated voltage 220V~50Hz 220V~50Hz 220V~50Hz 380V 3N~50Hz
Cooling and heating Nominal cooling
capacity
7.8kW(2kW-9kW) 13kW(3kW-15kW) 14.5kW(4kW-16.5kW) 14.5kW(4kW-16.5kW)
Nominal cooling power
consumption
2.77KW 4.6KW 5.27KW 5.27KW
Nominal cooling(COP) 2.81 2.82 2.75 2.75
IPLV 4.11 4.13 4.02 4.02
Nominal heating capacity 8.4kW(2.5kW-9.6kW) 14kW(3.5kW-16kW) 17kW(4.3kW-18.5kW) 17kW(2.5kW-18.5kW)
Nominal heating power
consumption
2.78KW 4.5KW 5.6KW 5.6KW
Heating Nominal heating capacity 6.8KW 10.5KW 13KW 13KW
Nominal heating
power consumption
1.75KW 2.65KW 3.3KW 3.3KW
Nominal heating(COP) 3.88 3.96 3.93 3.93
Maximum operating current 20A 33A 41A 21A
Maximum power consumption 4KW 6.6KW 7.9KW 7.9KW
Rated water flow 1.34m²/h 2.24m²/h 2.5m²/h 2.5m²/h
Refrigerant/charge volume R410A/1750g R410A/4000g R410A/4000g R410A/4800g
noise ≤54dB(A) ≤56dB(A) ≤57dB(A) ≤58dB(A)
Water resistance ≤14kPa ≤15kPa ≤21kPa ≤21kPa
Maximum working pressure on low
pressure/high pressure side
4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa
Allowable working pressure on
suction/exhaust side
4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa 4.5Mpa/0.15Mpa
Anti-shock level I I I I
waterproof level IPX4 IPX4 IPX4 IPX4
Unit size (l× w × h) 1030×410×865(mm) 1030×410×1390(mm) 1030×410×1390(mm) 820×780×1700(mm)
(Cold and warm) Caliber of inlet
and outlet
DN25 DN32 DN32 DN32
(Hot water) Caliber DN20 DN25 DN25 DN25
Application area 60㎡ 100㎡ 110㎡ 110㎡


Nominal refrigeration conditions: ambient dry bulb 35℃, outlet temperature 7℃. Nominal heating conditions: ambient dry bulb 7℃, ambient wet bulb 6℃,outlet temperature 45℃
Nominal hot water production conditions: ambient dry bulb 20℃, ambient wet bulb 15℃, initial water temperature 15℃, end water temperature 55℃.
DC Inverter Split System Heat Pump IPX4 Heat Pump Heating And Cooling System 0DC Inverter Split System Heat Pump IPX4 Heat Pump Heating And Cooling System 1
