18 Kw DC Inverter Air Source Heat Pump Air to Water Monoblock Type with Smart WiFi Remote Control
This 18 Kw DC Inverter Air Source Heat Pump Air to Water Monoblock Type with Smart WiFi Remote Control adopts a water supply intelligent control system, including heat pump, solenoid valve, water pump, hot water tank, cold water tank, liquid level, temperature sensor; a temperature sensor is set in the water tank, and the air source heat pump is connected to the water tank water pipe connection On the pipe, the air source heat pump, solenoid valve, water pump, liquid level, and temperature sensors are connected to the central control system. The invention can ensure that the heat pump unit is always running under low pressure, make up for the deficiencies of the general heat pump hot water system control method, and realize the intelligent control purpose of high efficiency and energy saving
6. Intergration of spares, space saving and flexible install
18 Kw DC Inverter Air Source Heat Pump Air to Water Monoblock Type with Smart WiFi Remote Control realizes cooling, heating and hot water at the same time, and one machine has three functions. It has high comprehensive energy efficiency and has both cooling and heating. High-quality heat exchanger, high-efficiency heat exchange and safe operation, water inside the tube, fluorine outside the tube, countercurrent heat exchange, higher efficiency; using intelligent defrosting technology, the defrosting time is shortened by more than 20%, and minus 30 degrees is still ultra-high energy efficiency.
It has the advantages of high efficiency, low noise, reasonable structure, simple operation, safe operation, convenient installation and maintenance, etc. It is widely used in hotels, shopping malls, office buildings, exhibition halls, airports, stadiums and other public places, and can meet the requirements of different industries for air conditioning systems. Different usage requirements
| Item | KFXRS-7I | KFXRS-11I | KFXRS-11II | KFXRS-19I |
| Nominal heating capacity at room temperature(kW) | 7.2 | 10.8 | 10.8 | 19 |
| Nominal input power at room temperature(kW) |
1.63 | 2.7 | 2.7 | 4.19 |
| Rated voltage(Hz) | 220V-50 | 220V-50 | 380V3N-50 | 220V-50 |
| Low temperature nominal heatingWkW) |
5.9 | 8.8 | 8.8 | 15.5 |
| Low temperature nominal input power(kW) |
1.62 | 2.65 | 2.65 | 4.18 |
| Maximum input power(kW) | 2.5 | 4.2 | 4.2 | 8 |
| Maximum current(A) | 11.5 | 23 | 8 | 32 |
| noisedb(A) | <51 | <63 | <63 | <66 |
| Anti-shock level | I | I | I | I |
| waterproof level | IPX4 | IPX4 | IPX4 | IPX4 |
| Caliber of inlet and outlet | DN20 | DN20 | DN20 | DN32 |
| Unit size (mm) | 1010x350x835 | 1030x410x865 | 1030x410x865 | 1030x410x1390 |
| Unit Weight kg) | 72 | 88 | 88 | 126 |
