Features of Air Source Heat Pump Water Heater Inverter 2020 OEM Heat Pumps HVAC System Hot Water Solution

Thermal expansion valve

Adjust the evaporator liquid supply to meet the demand of refrigeration system load. Control the evaporator outlet refrigerant superheat, and ensure the evaporator heat transfer efficiency and avoid the occurrence of "liquid strike".

Temperature compensation function

The system has two optional operation modes: fixed and weather compensation. When choosing the climate compensation mode, according to the outdoor temperature change, the system according to the temperature compensation curve, automatically adjust the water supply temperature, ensure the indoor temperature is suitable and stable, avoid the indoor temperature honest replacement and overheating phenomenon. Luyu air source heat pump can set the temperature compensation within ±5℃ according to the needs of users to improve the comfort of users.

Subregional control

Free adjustment of heating time and heating temperature according to temperature needs. It can also realize household, stratification and room heating

While saving energy, it can meet the needs of different users.

* Super wide 8 rows of windward area design

Super wide 8 rows of windward area design, increase the heat absorption rate, make the heat exchanger more efficient, more uniform, more sufficient heat transfer.

Stepless variable speed, high efficiency and low consumption

Keep energy saving hot water uninterrupted

Special steel plate

Adopt special steel plate, zinc plating, rust prevention, corrosion prevention and other special processes, strong toughness, anti-shedding, and acid resistance, corrosion resistance.

Stepless speed regulation, light weight, large output

Hot water, heating and refrigeration do not conflict with each other

Special energy-efficient wings

Slice heat exchanger

Adopting special new hydrophilic aluminum foil, the unique hydrophilicity makes the condenser not easy to form a water bridge, ensuring heat dissipation and smooth heat transfer. Its hydrophilic ability is strong, the effect of lotus leaf is obvious, the heat transfer effect is good.

Smart touch screen saves time and worry

A variety of needs can be met by one key

Sheet metal integrated body design

The square aesthetic of vision

Adopt rice gold integrated design,

Small footprint,

Art vision, for you to create a heat pump heating noble quality of life

Patented high/low temperature air injection enthalpy increase technology

Company intropduction
20 years of professional heat pump system technology excellence
We give full play to the advantages of scientific and technical personnel, and constantly overcome the technical bottlenecks in the field of air energy water heater. We have obtained 120 invention patents, more than 350 other patents, and participated in the preparation of 25 national standards.

Our strong and professional technical and marketing team ready to make best service!

• Technical paremeters for Air Source Heat Pump Water Heater Inverter 2020 OEM Heat Pumps HVAC System Hot Water Solution

• Item KCHR-13I/BP Side wind) Rated voltage 220V~50Hz Cooling and heating Nominal cooling capacity 13kW(3kW-15kW) Nominal cooling power consumption 4.6KW Nominal cooling(COP) 2.82 IPLV 4.13 Nominal heating capacity 14kW(3.5kW-16kW) Nominal heating power consumption 4.5KW Heating Nominal heating capacity 10.5KW Nominal heating power consumption 2.65KW Nominal heating(COP) 3.96 Maximum operating current 33A Maximum power consumption 6.6KW Rated water flow 2.24m²/h Refrigerant/charge volume R410A/4000g noise ≤56dB(A) Water resistance ≤15kPa Maximum working pressure on low pressure/high pressure side 4.5Mpa/0.15Mpa Allowable working pressure on suction/exhaust side 4.5Mpa/0.15Mpa Anti-shock level I waterproof level IPX4 Unit size (l× w × h) 1030×410×1390(mm) (Cold and warm) Caliber of inlet and outlet DN32 (Hot water) Caliber DN25 Application area 100㎡

• Nominal refrigeration conditions: ambient dry bulb 35℃, outlet temperature 7℃. Nominal heating conditions: ambient dry bulb 7℃, ambient wet bulb 6℃,outlet temperature 45℃
• Nominal hot water production conditions: ambient dry bulb 20℃, ambient wet bulb 15℃, initial water temperature 15℃, end water temperature 55℃.
•
•
