Features of -25C cold winter monoblock air source new energy heat pump inverter heatpump air to water
Product model: low temperature frequency conversion air energy heat pump heating and cooling machine
Applicable: factories, schools, hotels, residential units that need air conditioning and heating.
Product introduction: ultra-low temperature frequency conversion air energy heat pump unit in the wide voltage range of 160 volts ~ 280 volts, stable operation under different voltage conditions, the maximum power of cooling or heating at the beginning of the work, when close to the temperature target value of low frequency output work, always maintain constant temperature demand energy balance. Is set energy saving, environmental protection, safety, high efficiency, comfortable in a body, is to improve the people. "cold and warm" life and work of the ideal choice.
Module intelligent centralized controller, automatic monitoring unit, users more worry; Unit air conditioning hot water - integrated design, simple and convenient installation, reduce costs; Multi-system design, more cost saving when users use; Efficient scroll compressor, good stability, COP up to 6.5, longer unit life; Unit can be freely combined, save investment; Different modes can be selected in different seasons to make the unit more energy saving. The operation of the unit is pollution-free.
Some specifications of -25C cold winter monoblock air source new energy heat pump inverter heatpump air to water
| Spec. | KRY-8II | KRY-12II | KRY-24II | KRY-48II | KRY-96II | KRY-145II | KRY-220II |
| Rated heating capacity(A24/26oC) | 8kw | 12kw | 24kw | 48kw | 96kw | 145kw | 220kw |
| Rated power(kW) | 1.56 | 2.35 | 4.7 | 9.3 | 18.5 | 23.6 | 42.5 |
| COP | 5.1 | 5.1 | 5.1 | 5.16 | 5.41 | 6.14 | 5.17 |
| Rated heating capacityA20/26oC | 7.5kw | 11kw | 21kw | 44 kw | 90kw | 138kw | 208kw |
| Rated power(kW) | 1..5 | 2.3 | 4.5 | 8.6 | 17.5 | 24.1 | 41.5 |
| COP | 5 | 4.78 | 4.66 | 5.11 | 5.14 | 5.73 | 5 |
| Cooling Capacity(kW) | 3.8 | 5.7 | 11.3 | 23.7 | 40 | 58.1 | 98 |
| Consumed Power(kW) | 1.67 | 2.5 | 4.9 | 9.1 | 18.2 | 24.2 | 39 |
| EER | 2.3 | 2.3 | 2.3 | 2.6 | 2.2 | 2.4 | 2.5 |
| Rated voltage(Hz) | 220V 50HZ | 220V 50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 2 | 3 | 6 | 12 | 24 | 36.5 | 61 |
| Maximum current(A) | 8 | 12 | 24 | 42 | 80 | 90 | 130 |
| Water flownWh | 2.3 | 3.5 | 7 | 13 | 32 | 41 | 62 |
| noise dB(A) | <50 | <50 | <65 | <68 | <69 | <71 | <73 |
| Anti-shock level | I | I | I | I | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 910x350x835 | 1030x410x865 | 780x820x1700 | 1550x780x1700 | 1550x1550x1700 | 2360x1550x1840 | 2206x2020x2170 |
| Unit Weight(kg) | 65 | 95 | 260 | 380 | 760 | 2100 |
4005 |
Application of High Industrial Screw Type Air Cool Air Source Heat Pump China
Villa, Hotels, restarants, household, swimming pool, spas, etc
Some of our projects
