Commercial High Temperature R744 CO2 Heat Pump For House Heating And Cooling
Negotiable
MOQ
Negotiable
Price
Commercial High Temperature R744 CO2 Heat Pump For House Heating And Cooling
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CE ISO CCC ROHS
Model Number: SJKRS-106 IC
High Light:

High Temperature R744 CO2 Heat Pump

,

90C CO2 Heat Pump

,

Air Source Heat Pump Water Heater

Payment & Shipping Terms
Packaging Details: standard export package, or as per customer request
Delivery Time: 1-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000pcs/year
Specifications
Referigeration: CO2 R744
Application:: Outdoor, Hotel, Commercial, Household
Use:: Space Heating, Cooling, Hot Water Solutions
Function:: Space Heating,Cooling & Hot Water
Max Hot Water Te: 70-90 C
Working Ambient Tem: -25C To 43C
Product Description

Commercial and Industrial High Temperature R744 CO2 air source Heat Pump house heating and cooling water heater

Commercial and Industrial Heat Pumps: CO2 Models Producing Hot Water

  • Transcritical carbon dioxide (CO2) industrial heat pumps are widely used for commercial and industrial applications in Japan. Mayekawa Manufacturing Company (MYCOM) offers commercial/industrial water heating EcoCute CO2 heat pumps with ratings up to 90 kW. This water-source CO2 heat pump water heater (HPWH) can supply 5,800 gallons per day of water at 194°F. This equipment typically costs 25% to 35% more than a boiler for water heating. This technology can be very useful for generating water hot enough for radiant floor heating and many industrial processes. For example, CO2 industrial heat pumps can extract the heat from fresh milk prior to refrigeration and use it to generate hot water for washing. These units require compressors that operate between 600 to 1,700 pounds per square inch gauge (psig). The heat pump Coefficient of Performance (COP) is not negatively impacted from high-pressure operation because the compressors operate at a low pressure ratio. MYCOM has obtained Underwriters Laboratories (UL) listings for their industrial heat pump products so, unlike the residential-scale version of this technology (E3TNW #389 Carbon-Dioxide Heat Pump Water Heaters)
  • The benefits of Commercial and Industrial High Temperature R744 CO2 air source Heat Pump house heating and cooling water heater include:

  • Carbon Dioxide is a natural, environmentally friendly alternative to traditional refrigerants.
  • Effective refrigeration with simultaneous heat production to a high-temperature level.
  • Effective heat recovery using industrial waste heat sources and wastewater.
  • Reduction of CO2 pollutant emissions through oil and gas savings.
  • Highly cost-effective – short payback period.
  • Premium quality, designed and produced in Germany in line with ISO 9001:2008.
  • Plant-side quality inspections such as pressure strength tests, leak tests and electrical tests are certified.
  • State-of-the-art control technology including remote monitoring.
  • Compact design.
  • Commercial and Industrial High Temperature R744 CO2 air source Heat Pump house heating and cooling water heater specification
Unit type SJKRS-28 II/C SJKRS-36II/C SJKRS-55 II/C SJKRS-73 I/C SJKRS-106 IC SJKRS-I60II /C
Specifications 7.5HP 10HP 15HP 20HP 30HP 40HP
Power supply Three-phase five-wire380V/50Hz
Heating mode Direct heat/cycle type
Standard working condition Heating capacity( kw ) 27.5 36.7 55.1 72.8 10.6.5 155.1
Input Power(kW) 6.1 8.2 13.7 16.1 23.6 34.5
COP 4.5 4.5 4.5 4.5 4.5 4.5
Hot Water flow(m³/h) 0.59 0.79 1.18 1.56 2.29 3.33
High temperature condition Heating capacity kw ) 23.9 28.5 51.5 59.5 89 13.1.5
Input Power(kW) 7.5 8.9 16.1 18.6 27.8 41.1
COP 3.2 3.2 3.2 3.2 3.2 3.2
Hot Water flow(m³/h) 0.27 0.33 0.59 0.68 1.02 1.51
Low temperature condition Heating capacity( kw ) 17.3 21.4 34.8 41.5 62.2 94.5
Input Power(kW) 6.2 7.6 12.4 14.8 22.2 33.8
COP 2.8 2.8 2.8 2.8 2.8 2.8
Hot Water flow(m³/h) 0.32 0.4 0.65 0.78 1.16 1.77
Component Information Size of water pipe joint DN20 DN25 DN32 DN40
Water heat exchanger Plate or sleeve heat exchanger
Air Heat Exchanger Aluminum Fin for copper tube
compressor type Semi-closed reciprocating
Operation Panel Color touch screen
Maximum outlet temperature(℃) 90℃
Refrigerants R744 (CO2 )
Design pressure(MPa) High side 15, low side 8
Dimensions (length, width and height mm) 1450x950x1450 1600x950x1500 1850x1150x1900 2050x1150x1950 2670x1410x2150 2290x2270x1980
Noise (dB) 56 59 62 67 70 70
Weight(kg) 550 660 780 860 1180 221360
SCOPE of use Feed water temperature(℃) 5~ 40
Feed water pressure 0.05~ 0.4
Effluent temperature(℃) 55~ 90
Maximum flow 1.2 1.5 2.4 3.2 4.9 6.5
Ambient temperature(℃) ’-20~43
