Swimming pool air energy water heater_pool heat pump unit product advantages:
1. Comfortable environment
The system can integrate dehumidification, air conditioning, ventilation (return air, exhaust air, fresh air and supply air), and pool water constant temperature integrated function design according to the use requirements of indoor constant temperature swimming pools, and reasonably control indoor ventilation, exhaust, fresh air, Pressure, temperature/humidity, and the heat recovered by the heat pump through dehumidification can be used for maintenance heating of the pool water. The water temperature is controlled at 26℃～28℃, the indoor air temperature is controlled at 28℃～30℃, and the humidity is controlled at 60% which is the most comfortable for the human body~ 70%, to achieve not only a constant pool water temperature, but also a constant air temperature and humidity in the pool area, so as to truly build a comfortable indoor swimming pool environment.
2. High efficiency and energy saving
The system is an energy recycling system, which can save up to 50% to 60% in annual operating costs compared to traditional systems.
3. Easy to manage
The system adopts a programmable microcomputer controller, and realizes the fully automatic operation of the system by setting the parameters of the swimming pool "air conditioning, dehumidification, and pool water heating". The control system can be incorporated into the building control system according to customer requirements to realize remote monitoring, control.
4. Safety and environmental protection
Use clean electric energy to power the heat pump system, and the refrigerant system uses R407C environmentally friendly refrigerant.
Leomon Swimming Pool Heat Pump Cooling and Heating DC Inverter energy efficient heat pumps patent technology of parts monoblock, flexible installing, users can install everywhere convienient
Swimming Pool Heat Pump Cooling and Heating DC Inverter energy efficient heat pumps specification
| Spec. | KRY-8II | KRY-12II | KRY-24II | KRY-48II | KRY-96II | KRY-145II | KRY-220II |
| Rated heating capacity(A24/26oC) | 8kw | 12kw | 24kw | 48kw | 96kw | 145kw | 220kw |
| Rated power(kW) | 1.56 | 2.35 | 4.7 | 9.3 | 18.5 | 23.6 | 42.5 |
| COP | 5.1 | 5.1 | 5.1 | 5.16 | 5.41 | 6.14 | 5.17 |
| Rated heating capacityA20/26oC | 7.5kw | 11kw | 21kw | 44 kw | 90kw | 138kw | 208kw |
| Rated power(kW) | 1..5 | 2.3 | 4.5 | 8.6 | 17.5 | 24.1 | 41.5 |
| COP | 5 | 4.78 | 4.66 | 5.11 | 5.14 | 5.73 | 5 |
| Cooling Capacity(kW) | 3.8 | 5.7 | 11.3 | 23.7 | 40 | 58.1 | 98 |
| Consumed Power(kW) | 1.67 | 2.5 | 4.9 | 9.1 | 18.2 | 24.2 | 39 |
| EER | 2.3 | 2.3 | 2.3 | 2.6 | 2.2 | 2.4 | 2.5 |
| Rated voltage(Hz) | 220V 50HZ | 220V 50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 2 | 3 | 6 | 12 | 24 | 36.5 | 61 |
| Maximum current(A) | 8 | 12 | 24 | 42 | 80 | 90 | 130 |
| Water flownWh | 2.3 | 3.5 | 7 | 13 | 32 | 41 | 62 |
| noise dB(A) | <50 | <50 | <65 | <68 | <69 | <71 | <73 |
| Anti-shock level | I | I | I | I | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 910x350x835 | 1030x410x865 | 780x820x1700 | 1550x780x1700 | 1550x1550x1700 | 2360x1550x1840 | 2206x2020x2170 |
| Unit Weight(kg) | 65 | 95 | 260 | 380 | 760 | 2100 | 4005 |
.
FAQ:
Q: What is your strength in heat pump industry?
A: Decades experience in the field of heat pumps for more than 19 years. Over 300 patents, leader member for ediiting heat pumps standard.
Q: Do you accept OEM & ODM?
A: Yes. We can supply products under clients' brand, modify the products to satisfy client's personalized requirements and work together with clients to design and produce a totally new products.
Q: What support do you offer to clients?
A: We can: provide product certification requirements for local markets; provide catalogs, technical manuals; co-exhibit with the clients in leading industry exhibitions; do promotion on the local market’s media by our news release resources.
Q: Could I have a sample to check the quality ?
A:Yes, sample order is okay.If the model in stock, we even can ship immediately.
Q:Why is air to water heat pump a recommended heating solution?
A:Using renewable energy reduces your environmental impact while allowing you to save money. A correctly installed air to water heat pump system that is specific to your home's dimension lowers your heating costs by up to 50%.
Welome to contact us For the most suitable Heating,Cooling,Hot Water Solution!
