Inverter Air Source Swimming Pool Heat Pump Water Heater Commercial
Negotiable
MOQ
Negotiable
Price
Inverter Air Source Swimming Pool Heat Pump Water Heater Commercial
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CB, CE, EMC, RoHS
Model Number: DKFXRS
High Light:

DC Inverter Swimming Pool Heat Pump

,

220kw Swimming Pool Heat Pump

,

Commercial Heat Pump Water Heater

Payment & Shipping Terms
Packaging Details: export package Woonden case or plastic film
Delivery Time: 1-30 days
Payment Terms: D/P, L/C, D/A, T/T, Western Union, MoneyGram,
Supply Ability: 50,000pcs/year
Specifications
Application: Villa Family, Sauna And Swimming Pool, Hotels, Factory Hospital, Student Apartments, Beauty Salons, SPA
Rated Heating Capacity(: 8-220 KW
Function: Heating, Cooling, Hot Water
Controller: Intelligent Control Wifi Control
Refrigerant: R134a, R22,R410
Heat Exchanger: Titanium Heat Exchanger
Working Enviroment: -25-50 Degree
Compressor: Copeland
Product Description

Commercial Inverter Air Source Swimming Pool Heat Pump Water Heater with Large Capacity

Commercial Inverter Air Source Swimming Pool Heat Pump Water Heater with Large Capacity

Swimming pool air energy water heater_pool heat pump unit product advantages:

1. Comfortable environment

The system can integrate dehumidification, air conditioning, ventilation (return air, exhaust air, fresh air and supply air), and pool water constant temperature integrated function design according to the use requirements of indoor constant temperature swimming pools, and reasonably control indoor ventilation, exhaust, fresh air, Pressure, temperature/humidity, and the heat recovered by the heat pump through dehumidification can be used for maintenance heating of the pool water. The water temperature is controlled at 26℃~28℃, the indoor air temperature is controlled at 28℃~30℃, and the humidity is controlled at 60% which is the most comfortable for the human body~ 70%, to achieve not only a constant pool water temperature, but also a constant air temperature and humidity in the pool area, so as to truly build a comfortable indoor swimming pool environment.

2. High efficiency and energy saving

The system is an energy recycling system, which can save up to 50% to 60% in annual operating costs compared to traditional systems.

3. Easy to manage

The system adopts a programmable microcomputer controller, and realizes the fully automatic operation of the system by setting the parameters of the swimming pool "air conditioning, dehumidification, and pool water heating". The control system can be incorporated into the building control system according to customer requirements to realize remote monitoring, control.

4. Safety and environmental protection

Use clean electric energy to power the heat pump system, and the refrigerant system uses R407C environmentally friendly refrigerant.



Leomon Commercial Inverter Air Source Swimming Pool Heat Pump Water Heater with Large Capacity patent technology of parts monoblock, flexible installing, users can install everywhere convienient



Commercial Inverter Air Source Swimming Pool Heat Pump Water Heater with Large Capacity

Swimming Pool Heat Pump Cooling and Heating DC Inverter energy efficient heat pumps specification

  • Spec. KRY-8II KRY-12II KRY-24II KRY-48II KRY-96II KRY-145II KRY-220II
    Rated heating capacity(A24/26oC) 8kw 12kw 24kw 48kw 96kw 145kw 220kw
    Rated power(kW) 1.56 2.35 4.7 9.3 18.5 23.6 42.5
    COP 5.1 5.1 5.1 5.16 5.41 6.14 5.17
    Rated heating capacityA20/26oC 7.5kw 11kw 21kw 44 kw 90kw 138kw 208kw
    Rated power(kW) 1..5 2.3 4.5 8.6 17.5 24.1 41.5
    COP 5 4.78 4.66 5.11 5.14 5.73 5
    Cooling Capacity(kW) 3.8 5.7 11.3 23.7 40 58.1 98
    Consumed Power(kW) 1.67 2.5 4.9 9.1 18.2 24.2 39
    EER 2.3 2.3 2.3 2.6 2.2 2.4 2.5
    Rated voltage(Hz) 220V 50HZ 220V 50HZ 380V 3N-50HZ 380V 3N-50HZ 380V 3N-50HZ 380V 3N-50HZ 380V 3N-50HZ
    Maximum input power(kW) 2 3 6 12 24 36.5 61
    Maximum current(A) 8 12 24 42 80 90 130
    Water flownWh 2.3 3.5 7 13 32 41 62
    noise dB(A) <50 <50 <65 <68 <69 <71 <73
    Anti-shock level I I I I I I I
    waterproof level IPV4 IPV4 IPV4 IPV4 IPV4 IPV4 IPV4
    Unit size (mm) 910x350x835 1030x410x865 780x820x1700 1550x780x1700 1550x1550x1700 2360x1550x1840 2206x2020x2170
    Unit Weight(kg) 65 95 260 380 760 2100 4005

.

Inverter Air Source Swimming Pool Heat Pump Water Heater Commercial 0Inverter Air Source Swimming Pool Heat Pump Water Heater Commercial 1

Inverter Air Source Swimming Pool Heat Pump Water Heater Commercial 2



FAQ:

Q: What is your strength in heat pump industry?

A: Decades experience in the field of heat pumps for more than 19 years. Over 300 patents, leader member for ediiting heat pumps standard.



Q: Do you accept OEM & ODM?

A: Yes. We can supply  products under clients' brand, modify the products to satisfy client's personalized requirements and work together with clients to design and produce a totally new products.



Q: What support do you offer to clients?

A: We can: provide product certification requirements for local markets; provide catalogs, technical manuals; co-exhibit with the clients in leading industry exhibitions; do promotion on the local market’s media by our news release resources.

Q: Could I have a sample to check the quality ?

A:Yes, sample order is okay.If the model in stock, we even can ship immediately.



Q:Why is air to water heat pump a recommended heating solution?

A:Using renewable energy reduces your environmental impact while allowing you to save money. A correctly installed air to water heat pump system that is specific to your home's dimension lowers your heating costs by up to 50%.


Welome to contact us For the most suitable Heating,Cooling,Hot Water Solution!
