Swimming Pool DC Inverter Heat Pump Low Carbon Route To Warm Water Stepless
Swimming Pool DC Inverter Heat Pump Low Carbon Route To Warm Water Stepless
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CB, ce, EMC, RoHS SABER
Model Number: KCHR-5I/BP Side wind
High Light:

Stepless DC Inverter Heat Pump


Low Carbon Inverter Heat Pump

Payment & Shipping Terms
Packaging Details: export packing
Payment Terms: L/C, T/T
Supply Ability: 50000units/year
TelAmbient Air Temp: -30 To 43 Degree Celsius
Function: Heating, Cooling
Rated Power: 24 KW
Energy Efficiency Grade: One
Heating Type: Air Source Circulating Heat
Working Medium: R410A
Product Description
Strength of most efficient Swimming Pool Heat Pumps Low Carbon Route to Warm Water STEPLESS DC INVERTER POOL HEAT PUMP
The air source adopts a double-layer structure design, which is separated from top to bottom to achieve a good working temperature in each area of ​​the unit, which improves the heat exchange effect of the evaporator and suppresses the generation of noise.
The customized blue hydrophilic film aluminum foil fin evaporator has a reasonable heat exchange area and a good thickness of four rows of copper tubes, so as to achieve a faster defrosting speed and a higher heat exchange efficiency
Large air volume, low noise saw-tooth axial flow fan to improve the heat exchange speed of the evaporator, excellent dynamic balance technology reduces the resonance of the fan during operation and further suppresses the generation of noise
The entire line of air source products are equipped with Emerson Copeland’s "ZW" heat pump compressors. The powerful "heart" gives Lipman a powerful air source. The jet enthalpy technology realizes the unit's high energy efficiency ratio and harsh operating environment.
The breakthrough use of multiple operating systems, multiple compressors to start or stop on demand, greatly improves the stability of the unit, can cope with the harsh operating environment, improve the performance of the unit, and reduce the operating energy consumption during use. Reduce the failure rate of the unit.
Adopt time control + differential pressure control, multi-point precise defrosting technology, complete defrosting in 2-3 minutes, to ensure that the user's demand does not drop in temperature, while effectively reducing the defrosting time and improving the defrosting effect. In cold winter, the unit is running Stable, low operating energy consumption, and comfortable user experience.
Some specification as the below, for further information, welcome to contact us!
Swimming Pool DC Inverter Heat Pump Low Carbon Route To Warm Water Stepless 0
Rated heating capacity(A24/26oC) 8kw 12kw 24kw 48kw 96kw 145kw 220kw
Rated power(kW) 1.56 2.35 4.7 9.3 18.5 23.6 42.5
COP 5.1 5.1 5.1 5.16 5.41 6.14 5.17
Rated heating capacityA20/26oC 7.5kw 11kw 21kw 44 kw 90kw 138kw 208kw
Rated power(kW) 1..5 2.3 4.5 8.6 17.5 24.1 41.5
COP 5 4.78 4.66 5.11 5.14 5.73 5
Cooling Capacity(kW) 3.8 5.7 11.3 23.7 40 58.1 98
Consumed Power(kW) 1.67 2.5 4.9 9.1 18.2 24.2 39
EER 2.3 2.3 2.3 2.6 2.2 2.4 2.5
Rated voltage(Hz) 220V 50HZ 220V 50HZ 380V 3N-50HZ 380V 3N-50HZ 380V 3N-50HZ 380V 3N-50HZ 380V 3N-50HZ
Maximum input power(kW) 2 3 6 12 24 36.5 61
Maximum current(A) 8 12 24 42 80 90 130
Water flownWh 2.3 3.5 7 13 32 41 62
noise dB(A) <50 <50 <65 <68 <69 <71 <73
Anti-shock level I I I I I I I
waterproof level IPV4 IPV4 IPV4 IPV4 IPV4 IPV4 IPV4
Unit size (mm) 910x350x835 1030x410x865 780x820x1700 1550x780x1700 1550x1550x1700 2360x1550x1840 2206x2020x2170
Unit Weight(kg) 65 95 260 380 760 2100 4005
