Features of 145 kw Over - Temperature Direct Heat Water Heater for Commercial and Industrial School Beauty SPA
Main functions
45 kw Over - Temperature Direct Heat Water Heater for Commercial and Industrial School Beauty SPA, the air source heat pump applied constant temperature difference control system for the water inlet and outlet of the swimming pool heat pump includes a water inlet pipe, the water inlet pipe is connected to the water pump, the water pump pipe is connected to a three-way valve, and the three-way valve is piped to the second heat exchanger, the compressor and the first heat exchanger in turn; The outlet pipe, the outlet pipe is connected to a three-way valve, and the other pipe of the outlet pipe is connected to the second heat exchanger, and the second heat exchanger is also connected to the throttle valve and the first heat exchanger in turn through the pipeline; the PLC controller, The PLC controller is respectively connected to the water inlet sensor installed at the water inlet pipe of the second heat exchanger and the water outlet sensor installed at the water outlet pipe, and the PLC controller is also connected with a three-way valve. This solution solves the problem of the heating capacity of the swimming pool heat pump being greatly affected by the ambient temperature during the heating process of the existing swimming pool heat pump, resulting in an excessive temperature difference between the inlet and outlet water, resulting in increased heat loss and excessive local temperature in the swimming pool.
Company brief introduction
Over 20 years production experience, thanks to R&D hard and smart working, company is authorized over 400 patents, products quality play a lead role in HVAC system field
Leomon heat pump is also leader member for editting swimming pool air source heat pumps stadnard, leader for HVAC system and heating projects
Already service for many projects such as spa, villa, tourisa spots,, hotels, hospitals, restarant, beauty care, etc
Our strong and professional technical and marketing team ready to make best service!
Technical paremeters of 145 kw Over - Temperature Direct Heat Water Heater for Commercial and Industrial School Beauty SPA
| Spec. | KRY-145II |
| Rated heating capacity(A24/26oC) | 145kw |
| Rated power(kW) | 23.6 |
| COP | 6.14 |
| Rated heating capacityA20/26oC | 138kw |
| Rated power(kW) | 24.1 |
| COP | 5.73 |
| Cooling Capacity(kW) | 58.1 |
| Consumed Power(kW) | 24.2 |
| EER | 2.4 |
| Rated voltage(Hz) | 380V 3N-50HZ |
| Maximum input power(kW) | 36.5 |
| Maximum current(A) | 90 |
| Water flownWh | 41 |
| noise dB(A) | <71 |
| Anti-shock level | I |
| waterproof level | IPV4 |
| Unit size (mm) | 2360x1550x1840 |
| Unit Weight(kg) | 2100 |
The nominal working conditions at room temperature are: ambient dry bulb 20°C, ambient wet bulb 15°C, initial water temperature 15°C, and ending water temperature 55. (2; The nominal low temperature conditions are: ambient dry bulb 72, ambient wet bulb 61, initial water temperature 15°C, and ending water temperature 55.
