IPV4 Air To Water Heating System 4.66 COP Hot Tub Heater Pump 50HZ
IPV4 Air To Water Heating System 4.66 COP Hot Tub Heater Pump 50HZ
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: LN
Certification: CE ISO CCC
Model Number: KRY-24II
High Light:

IPV4 Air To Water Heating System


4.66 COP Hot Tub Heater Pump


50HZ Hot Tub Heater Pump

Payment & Shipping Terms
Packaging Details: standard export package, or as per customer request
Delivery Time: 1-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000pcs/year
Heating Capacity(A24/26oC): 24 Kw
Type: Constant Instant Hot Water Air Source Heat Pump Heater
Application:: Villa Family, Hotels, Factory Hospital, Student Apartments
Running Temp: Instant Hot Water -25℃~45℃
Tank: Enamel Water Tank
Heating Type: Circulating Heat
Product Description

Air To Water Heating System Hot Water solution


Features of Air To Water Heating System Hot Water Solution

Main features

Main functions

· Heating, cooling and hot water

There are 3 modes: heating , cooling and hot water.The combination of the modes extends the utilization of Suoher DC inverter heat pumps to the whole year. Users can choose the following modes.


-Hot water

-Heating+hot water-Cooling

-Cooling +hot water

·Adjustable defrosting setting

The climate is different in temperature and humidity in different area . Suoher Dc inverter heat pump controller offers adjust able defrosting setting to fit local climate,in order to reach the best balance between humidity and defrosting efficiency.

·DC inverter variable fan speed

The DC inverter fans offer full range variable air volume to fit the heating demands,and optimize the efficiency. Besides,DC fan motors have lower noise than AC fan motors.

·Adjustable operation ambient

temperature range

The operation ambient temperature range can be adjustable according to the practical combination of the whole heating system , in order to achieve the best heating output and efficiency of the whole heating system. All the protecting functions in the controller still operate to protect the heat pump system.

·Settable electric heater function

The indoor heating system can be different,example floor heating , fan coil units ,or radiators with different heating water temperature.The conditions for boosting the electric heater could be adjustable , to fit different types of indoor heating.

·Heating Curves

The inbuilt heating curves help to create the more comfortable indoor temperature for users.The heating curves can be adjustable by users according to their living habit,Also,heating curves help to save more energy.

·AUTO Sterilization for hot water

The hot water mode contains the AUTO sterilization function once every week,heating the hot water by electric heater up to 65DegC and keeping 15min. This function is enabled when hot water mode is enabled and runs fully automatically.

. Works with heating demand signal

One heating system would contain different types of heating , and choose the suitable heater for energy saving as per condition changes. Suoher DC inverter heat pump controller receives a remote ON/OFF signal of 230V to start/standby. This ON/OFF signal can be from solar controller, room thermostat,or the master controller of the house heating system.

·Circulation pump setting for heating /cooling

The circulation pump working mode in heating / cooling circuit can be adjustable according to practical conditions of the heating system.

·Smart phone APP control

The heat pump can be controlled by smartphone APP. The APP can monitor mode,status and errors, and can operate power on/off, mode setting, temperature setting and timer function,all the necessary functions that users may need.

. Other functions

-Works with solar system.-Memory function.

-Displays all symbols on controller screen.-All protections for refrigerant system.-All protections for water circuits.


Company brief introduction
Over 20 years production experience, thanks to R&D hard and smart working, company is authorized over 400 patents, products quality play a lead role in HVAC system field

Leomon heat pump is also leader member for editting swimming pool air source heat pumps stadnard,  leader for HVAC system and heating projects

Already service for many projects such as spa, villa, tourisa spots,, hotels, hospitals, restarant, beauty care, etc


We are China supplier for air source heat pumps, fan coil and related HVAC products, used for swimming pool, hotel, hospital, school,household,spa, wherever neeed hot water
Products series: swimming pool/spa  air source heat pumps
                         All in one triple multifunctional heat pumps: heating(Central heating ,floor heating, radient heating)+cooling+ hot water or seperate                             function
                        Heat pumps water heater
as leader for air source heat pumps, decades experience,authorized over100 patents, leader for swimming pool air source heat pumps and other pumps, member for editing heat pumps field standards, strong and professional technical team

Our strong and professional technical and marketing team ready to make best service!

Technical paremeters of Air To Water Heating System Hot Water Solution

Constant temperature swimming pool heat pump
Spec. KRY-24II
Rated heating capacity(A24/26oC) 24kw
Rated power(kW) 4.7
COP 5.1
Rated heating capacityA20/26oC 21kw
Rated power(kW) 4.5
COP 4.66
Cooling Capacity(kW) 11.3
Consumed Power(kW) 4.9
EER 2.3
Rated voltage(Hz) 380V 3N-50HZ
Maximum input power(kW) 6
Maximum current(A) 24
Water flownWh 7
noise dB(A) <65
Anti-shock level I
waterproof level IPV4
Unit size (mm) 780x820x1700
Unit Weight(kg) 260
Unit Price usd/set 1820
